Types of Led strips lights (1)
Today, Xinjielighting, a professional Led strips light manufacturer in China, will introduce the common types of Led strips lights according to SMD lamp beads, and help you distinguish various Led strips lights. Interested partners can’t help taking a few minutes to take a look together.
The composition of Led strips light is generally composed of a substrate (flexible or hard bottom), lamp beads, and other accessories. The core part is the LED lamp beads, which are generally dominated by SMD chip lamp beads. Then, we can divide Led strips light into:
SMD5050 Led strips light
5050 is the earliest form of lamp bead package that appeared. The initial power is very low, generally 0.1-0.2W, but with the development of technology, there are already SMD5050Led strips light of 1W-3W.
Moreover, because the 5050 lamp bead is large in size and has many changes, it can be made into RGB, RGWB, and Shenzhen encapsulates the control IC into the lamp bead.
Generally, there are 6 pads. If the control aspect is added, there may be as many as 8 pads.
SMD2835Led strips light
2835 is the most widely used and most mature package form besides 5050. Power from 0.1W to 1W, widely used in various downlights, brackets, Led strips light, and even outdoor lamps, floodlights and so on.
The 2835 package generally has only two pads, positive and negative, so monochrome temperature lamp beads are mainly used. Generally can not do dual color temperature, or RGB. However, it has stable performance, good heat dissipation and high luminous efficiency, and is the most common type of Led strips light.
SMD3014Led strips light
3014 appeared earlier than 2835, the power is small, generally only 0.1W, and the volume and luminous surface are also small. The earliest use on the backlight is the advantage of small size. Used on Led strips light, no matter in terms of brightness or luminous surface, it is not as good as 2835.
SMD3528Led strips light
3528 is second only to 5050 and is the elder brother of 3014 and 2835. Its volume is larger than that of 2835, and its power is similar to that of 3014. With the widespread use of 2835, 3528 lamp beads have gradually withdrawn from the market.
SMD5730/5630Led strips light
5730 or similar 5630, it is the same package type. This type of light-emitting surface is large, and the power is also large, generally 0.5-1W. If used on Led strips light, the power of a single lamp bead is too large, and the power and brightness of the entire Led strips light will be high. Of course, the cost is also higher. Therefore, it is generally not used much, and it is commonly used on high-voltage 220vLed strips light.
COBLed strips light
COB means chips on board, which means that the light-emitting chips are directly placed on the substrate, so there is no need for gold wires and brackets. A layer of phosphor powder is then potted on the surface. This is a relatively new Led strips light product, with high brightness, uniform luminous strips, and no graininess. Moreover, it is more tensile than normal SMDLed strips light. It will be the mainstream of Led strips light in the future.
In general, Led strips light is classified according to SMD lamp beads, which are mainly divided into COBLed strips light, SMD5730/5630Led strips light, SMD3528Led strips light, SMD3014Led strips light, etc. I believe that the partners who read the full text are all familiar with the above types of Led strips light. After understanding, more information about LED lamps can be found on the official website of Xinjielighting.
