Do you know what Sensor Panel Light is?

In this article, Xinjielighting, a professional Sensor Panel Light manufacturer, will introduce the application scope, working principle and functional characteristics of Sensor Panel Light. Help everyone better understand it.

Sensor Panel Light application range:

It is especially suitable for sensitive areas such as aisles and corridors in enterprises, hotels, shopping malls, warehouses, and households, or for automatic lighting, lighting and alarm systems in safe areas.

How Sensor Panel Light works:

Human body induction: Sensor Panel Light is based on infrared induction automatic control technology. When someone enters the sensing area, the special sensor detects the change of the infrared spectrum of the human body, which will trigger the signal to be amplified and processed by the CPU, and start the work of the LED driver. When the person leaves the Sensor In the sensing area of the Panel Light, after the set delay time, the Sensor Panel Light will automatically turn off and be in an ultra-low power sleep state.

Light sensing: When the external light is strong, such as during the day, the light sensing element transmits the real-time light signal value to the control circuit, and the control circuit will lock the switch of the human body Sensor Panel Light according to the light value, so that the whole light is in a dormant state, even if someone enters In the sensing area, the light will not be on, so that the Sensor Panel Light can realize humanized energy saving and intelligent power saving.

Sensor Panel Light features:

Fully automatic induction: when someone enters the sensing range of the Sensor Panel Light, it outputs a high level, and when someone leaves the sensing range of the Sensor Panel Light, the high level is automatically turned off and a low level is output.

Photosensitive control (optional): The module has a reserved position, and photosensitive control can be set. It does not sense during the day or when the light is strong. Photosensitive control is an optional function. Sensor Panel Light does not have a photoresistor installed at the factory. If necessary, please explain or purchase and install it yourself.

Repeatable trigger mode: that is, after the Sensor Panel Light senses the output high level, within the delay range, if there is a human body moving within the sensing range, it will keep the output high level until the delay will be high level after the person leaves. Changes to low level (the Sensor Panel Light will automatically extend a delay period after detecting each activity of the human body, and the time of the last activity is the starting point of the delay time)

With induction blocking time: (default setting is 0.2 seconds) After each output of the Sensor Panel Light induction module (high level changes to low level), a blocking time can be followed, and the Sensor Panel Light sensor does not accept any Signal. This function of Sensor Panel Light can realize the interval work of (sensing output time and blocking time), which can be applied to interval detection products; meanwhile, this function of Sensor Panel Light can effectively suppress various interference signals generated during the load switching process.

The above is the whole content of Sensor Panel Light brought to you by Xinjielighting. I hope that the introduction of this article can help you get to know Sensor Panel Light initially. For more lighting related information, please refer to our previous wonderful articles:
